Aiwa CSD-EL33 Service Manual

4
REF. NO PART NO. KANRI DESCRIPTION
NO.
REF. NO PART NO. KANRI DESCRIPTION
NO.
ELECTRICAL MAIN PARTS LIST
IC
87-A20-459-010 C-IC,LC78622ED
8Z-CH1-622-010 IC,LC867132V-5G68
87-A21-184-010 IC,TA2104AN
87-A21-185-040 C-IC,LC72121M
87-001-982-010 IC,TA7291S
87-A21-103-040 C-IC,MM1454XFBE
87-A20-715-010 IC,M62439SP
87-A20-591-010 IC,BA5417
87-017-889-010 IC,NJM4558LD
87-017-804-010 IC,BU4052BC
87-070-282-010 IC,BU2092
87-A20-446-010 C-IC,LA9241ML
87-A21-093-010 IC,LA6541D
87-070-416-010 IC,NJU7201 L55
87-A20-911-010 IC,RPM6938
87-020-454-010 IC,DN6851
TRANSISTOR
87-026-291-080 TR,DTC124XS
89-213-702-080 TR,2SB1370E
89-319-233-080 TR,2SC1923 (0.1W)
87-026-447-080 TR,2SC1740S R
89-320-011-080 TR,2SC2001K(15W)
87-026-215-080 TR,DTC114YS
89-318-155-080 TR,2SC1815GR(0.4W)
87-A30-090-080 FET,2SK2541
87-A30-151-080 TR,2SA1993
87-026-610-080 TR,KTC3198GR
87-A30-154-080 TR,RT1N441S
87-026-463-080 TR,2SA933SRS(0.3W)
89-113-187-080 TR,2SA1318TU
87-026-464-080 TR,DTC114TS
87-026-486-080 TR,DTA144TS
87-026-502-080 TR,DTC144TS
87-026-245-080 TR,DTC114ES
89-109-521-080 TR,2SA952K(0.6W)
89-112-965-080 TR,2SA1296GR(0.75W)
DIODE
87-017-072-080 ZENER,HZS3B1
87-A40-292-080 ZENER,DZ2.7L
87-017-139-080 ZENER,HZS15-2
87-070-345-080 DIODE,IN4148
87-027-606-080 ZENER,HZ7C2L(200MA)
87-017-148-080 ZENER,HZS6A1L
87-017-159-080 ZENER,HZS7B3L
87-A40-465-010 DIODE,FR202
MAIN C.B
C101 87-A10-182-010 CAP,CER 0.01-50 Z F
C102 87-010-112-080 CAP, ELECT 100-16V
C205 87-010-401-080 CAP, ELECT 1-50V
C206 87-010-401-080 CAP, ELECT 1-50V
C211 87-010-405-080 CAP, ELECT 10-50V
C212 87-010-405-080 CAP, ELECT 10-50V
C219 87-010-375-010 CAP,E 330-10 SME
C221 87-010-263-080 CAP, ELECT 100-10V
C222 87-010-405-010 CAP 50-10SME
C223 87-010-405-010 CAP 50-10SME
C224 87-010-380-080 CAP, ELECT 47-16V
C232 87-A10-170-010 CAP,CER 330P-50 K B
C233 87-010-382-080 CAP, ELECT 22-25V
C235 87-A10-175-010 CAP,CER 820P-50 K B
C236 87-A10-175-010 CAP,CER 820P-50 K B
C237 87-010-401-080 CAP, ELECT 1-50V
C238 87-010-401-080 CAP, ELECT 1-50V
C251 87-010-400-080 CAP, ELECT 0.47-50V
C252 87-010-400-080 CAP, ELECT 0.47-50V
C255 87-010-546-080 CAP, ELECT 0.33-50V
C256 87-010-546-080 CAP, ELECT 0.33-50V
C257 87-010-544-080 CAP, ELECT 0.1-50V
C258 87-010-544-080 CAP, ELECT 0.1-50V
C261 87-010-263-080 CAP, ELECT 100-10V
C262 87-010-408-080 CAP, ELECT 47-50V
C269 87-010-402-080 CAP, ELECT 2.2-50V
C270 87-010-402-080 CAP, ELECT 2.2-50V
C271 87-010-401-080 CAP, ELECT 1-50V
C272 87-010-401-080 CAP, ELECT 1-50V
C275 87-010-382-080 CAP, ELECT 22-25V
C276 87-010-382-080 CAP, ELECT 22-25V
C277 87-010-260-080 CAP, ELECT 47-25V
C278 87-010-384-080 CAP, ELECT 100-25V
C279 87-010-235-080 CAP,E 470-16 SME
C281 87-010-380-080 CAP, ELECT 47-16V
C282 87-010-380-080 CAP, ELECT 47-16V
C283 87-010-236-080 CAP,E 1000-10 SME
C284 87-010-236-080 CAP,E 1000-10 SME
C287 87-018-125-080 CAP, CER 330P-50V
C288 87-018-125-080 CAP, CER 330P-50V
C291 87-010-401-080 CAP, ELECT 1-50V
C292 87-018-119-080 CAP, CER 100P-50V
C305 87-010-263-080 CAP, ELECT 100-10V
C306 87-010-263-080 CAP, ELECT 100-10V
C311 87-010-546-080 CAP, ELECT 0.33-50V
C312 87-010-546-080 CAP, ELECT 0.33-50V
C323 87-A10-170-010 CAP,CER 330P-50 K B
C324 87-A10-170-010 CAP,CER 330P-50 K B
C331 87-A10-171-010 CAP,CER 390P-50 K B
C332 87-A10-171-010 CAP,CER 390P-50 K B
C333 87-A10-173-010 CAP,CER 560P-50 K B
C340 87-010-382-080 CAP, ELECT 22-25V
C347 87-010-374-080 CAP, ELECT 47-10V
C363 87-010-405-080 CAP, ELECT 10-50V
C364 87-010-405-080 CAP, ELECT 10-50V
C369 87-A10-163-010 CAP,CER 82P-50 K SL
C370 87-A10-163-010 CAP,CER 82P-50 K SL
C373 87-010-401-080 CAP, ELECT 1-50V
C374 87-010-401-080 CAP, ELECT 1-50V
C382 87-010-401-080 CAP, ELECT 1-50V
C383 87-010-248-080 CAP, ELECT 220-10V
C384 87-010-374-080 CAP, ELECT 47-10V
C401 87-010-403-080 CAP, ELECT 3.3-50V
C402 87-018-134-080 CAPACITOR,TC-U 0.01-16
C403 87-010-263-080 CAP, ELECT 100-10V
C404 87-010-248-080 CAP, ELECT 220-10V
C405 87-018-134-080 CAPACITOR,TC-U 0.01-16
C406 87-010-374-080 CAP, ELECT 47-10V
C409 87-010-248-080 CAP, ELECT 220-10V
C410 87-010-263-080 CAP, ELECT 100-10V
C412 87-010-401-080 CAP, ELECT 1-50V
C414 87-010-405-080 CAP, ELECT 10-50V
C416 87-010-545-080 CAP, ELECT 0.22-50V
C417 87-018-125-080 CAP, CER 330P-50V
C425 87-018-129-080 CAP, CER 680P-50V
C430 87-018-123-080 CAP, CER 220P-50V
C431 87-010-545-080 CAP, ELECT 0.22-50V
C432 87-010-374-080 CAP, ELECT 47-10V
C433 87-010-401-080 CAP, ELECT 1-50V
C435 87-018-134-080 CAPACITOR,TC-U 0.01-16
C436 87-010-374-080 CAP, ELECT 47-10V
C437 87-010-404-080 CAP, ELECT 4.7-50V
C438 87-018-209-080 CAP, CER 0.1-50V
C440 87-018-139-080 CAP,TC U 1P-50 CH
C442 87-018-149-080 CAP,TC U 15P-50 J CH
C445 87-018-209-080 CAP, CER 0.1-50V
