ENGLISH 9
PROGRAMMED PLAY
Up to 16 tracks can be programmed from the disc.
1
In stop mode, press PROGRAM.
2
Press r, t to select a track, then
press PROGRAM to store it.
3
Repeat step 2 to program other tracks.
4
Press s to finish the program.
5
Press e to start play.
To check the program, press r or t in stop
mode.
To clear the program, hold down PROGRAM in stop
mode until the display changes.
To change the programmed tracks, clear the
program and repeat all the steps again.
Specifications
Tuner section
Frequency range, antenna – FM: 87.5 - 108.0 MHz Rod
antenna, AM: 530/531 - 1,710/1,602 kHz (10/9 kHz
step) Ferrite bar antenna
Deck section
Track format – 4 tracks, 2 channels / Frequency range
– Normal tape: 50 - 12,500 Hz (EIAJ) / Recording
system – AC bias / Erasing system – Magnet erase /
Heads – Recording/playback head (1), Erasure head
(1)
CD player section
Disc – Compact disc / Scanning method – Non-contact
optical scanner (semiconductor laser)
General
Speaker – 100 mm cone type (2) / Power output –
2 W + 2 W (EIAJ 8 ohms, T.H.D. 10% DC) / Power
requirements – DC 12 V using eight size C (R14)
batteries, AC 120 V, 60 Hz / Power consumption – 12
W / Dimensions (W × H × D) – 390 × 167 × 255.5 mm /
Weight (excluding batteries) – 2.7 kg / Accessory –
Remote control (1, CSD-TD19 only), AC cord (1)
Specifications and external appearance are subject to
change without notice.
COPYRIGHT
Please check the copyright laws relating to
recordings from disc, radio or external tape for the
country in which the machine is being used.
If an erroneous display or malfunction occurs
Select CD function first. Hold down s and press e.
If the unit cannot be reset in the way above, disconnect
the AC cord and remove all the batteries to turn off the
display.
Leave the unit for a while and turn the power back on.
En
Track number
Program number
Total number of
the programmed tracks
REPEAT/
MODE/OSC
r, t
SKIP/SEARCH
e
PLAY/PAUSE
PROGRAM
s
STOP/BAND
(CSD-TD19 only)
