AJA FiDO-TR - FIDO-R-ST

FiDO 3G Series SDI/Optical Fiber Mini-Converters v1.2 22 www.aja.com
FiDO-R-ST
Video Formats
• 150 Mbps - 3 Gbps, format agnostic
Video Input Digital
• 1-channel 3G-SDI Single Mode ST Fiber Input connector, SMPTE-297
• Nominal Wavelength: 1260 - 1620 nm
• Optical Sensitivity: -18dBm (Max)
• Overload Power: -3dBm (Min)
Video Output Digital
• 1-channel Dual matching 3G-SDI BNC Outputs, SMPTE-259/292/424
Reclocking
• 270 Mbps, 1.483 Gbps, 1.485 Gbps, 2.966 Gbps, 2.970 Gbps - Auto Select
• All other rates are passed through and not reclocked
Size (w x d x h)
• 4.6" x 1.71" x 0.85" (117.0 x 43.5 x 21.6mm)
Weight
• 0.5 lb (0.3 kg)
Power
• 2 watts, max
• Uses 5-20VDC power, AJA power supply model DWP-U-R1 included
Environment
• Safe Operating Temperature: 0 to 40 C (32 to 104 F)
• Safe Storage Temperature (Power OFF): -40 to 60 C (-40 to 140 F)
• Operating Relative Humidity: 10-90% noncondensing
• Operating Altitude: <3,000 meters (<10,000 feet)
