Chapter 1 – Introduction
Overview
FiDO SDI/Optical Fiber Mini-Converters allow the transport of 3G-SDI over
distances of up to 10km (Single-Mode), 700M (OM4) and 300M (OM3) for Multi-
Mode fiber optic cable. The compact, low profile enclosure is perfect for use in
tight spaces such as equipment racks, trucks and crowded facilities. Choose from
LC, ST, or SC connectors, depending on the converter model, for unmatched
flexibility and cost efficiency.
FiDO Mini-Converters meet all relevant SMPTE specifications as well as offering
electrical isolation to eliminate potential ground loop problems for a rugged,
versatile solution that is suitable for a variety of applications.
Features
• Transport of 3G/HD/SD-SDI as well as DVB-ASI over optical fiber
• Automatic detection and re-clocking of 270Mb, 1.5Gb, and 3Gb SDI data rates
• Coax inputs are equalized
• Coax and fiber inputs are reclocked
• All SDI ancillary data including embedded audio is passed
• LC, ST or SC fiber connectors
• Simplex, duplex or quad models available
• Useful for eliminating ground loop problems
• Multi-Mode fiber options (with LC connectors) are available for FIDO models
with SFP cages
• DWP-U-R1 power supply included
• Five Year warranty
Single-Mode FiDO Models (1310 nm)
• FiDO-TR: Single channel SDI/LC fiber Transceiver
• FiDO-T: Single channel SDI to LC fiber Transmitter with looping SDI output
• FiDO-R: Single channel LC fiber to SDI Receiver with dual SDI outputs
• FiDO-2T: Dual channel SDI to LC fiber Transmitter
• FiDO-2R: Dual channel LC fiber to SDI Receiver
• FiDO-4T: Quad channel SDI to LC fiber Transmitter
• FiDO-4R: Quad channel LC fiber to SDI Receiver
• FiDO-T-SC: Single channel SDI to SC fiber Transmitter with looping SDI output
• FiDO-R-SC: Single channel SC fiber to SDI Receiver with dual SDI outputs
• FiDO-T-ST: Single channel SDI to ST fiber Transmitter with looping SDI output
• FiDO-R-ST: Single channel ST fiber to SDI Receiver with dual SDI outputs
• FiDO-4T-ST: Quad channel SDI to ST fiber Transmitter
• FiDO-4R-ST: Quad channel ST fiber to SDI Receiver
