Appendix A: Specifications
Specifications
SDI I/O SD/HD-SDI (auto-selected), SMPTE-292/296/424, 1x BNC
Formats:
• 525i59.94, 625i50
• 1080i 50/59.94
• 720p 23.98/24/25/29.97/30/50/59.94/60
• 1080p 23.98/24/25/29.97/30/59.94/60
• 1080psf 23.98/24/25/29.97/30
Reference Input • Color Black
•Tri-Level sync
HDMI Output 10-bit HDMI v1.4a
Formats:
• 525i29.97, 625i50
• 1080i 50/59.94/60
• 720p 23.98/24/25/29.97/30/50/59.94/60
• 1080p 23.98/24/25/29.97/30/59.94/60
NOTE: HDMI monitors may not properly support all frame rates or "pSF" formats.
Audio I/O • 16-channel embedded SDI audio input
• 16-channel embedded SDI audio output
• 8-channel HDMI audio output
• 2 RCA-style analog outputs at -10dBV (nominal)
HDCP The UDC does not encode the HDMI output with HDCP encryption. By definition, HD-SDI
inputs to the UDC are unencrypted. The HDMI specification requires HDMI monitors to
support unencrypted inputs.
User Controls USB port used with supplied cable and MiniConfig software application to configure
device via PC/Mac.
Size 5.8" x 3.1" x 1 (147mm x 79mm x 25mm)
Power Uses AJA Power Supply model DWP-U-R1 (included)
• 100-240V, 50/60Hz Universal Input
• +5V DC regulated, 7.5 watt capacity
