87
Rev 2.1
Configure → Lead Lag Master Configuration → Advanced Setting → Drop Stage → Detection Time Textbox
(Default: 0m30s)
• Type in desired time
This parameter determines how long drop stage condition needs to persist for drop stage to occur.
5-23.3 To Change Drop Stage Error Threshold
Configure → Lead Lag Master Configuration → Advanced Setting → Drop Stage → Error Threshold Textbox
(Default: 5F)
• Type in desired degree
This parameter determines error based on degree away from setpoint for drop stage condition to occur.
5-23.4 to change drop stage rate offset
Configure → Lead Lag Master Configuration → Advanced Setting → Drop Stage → Rate Offset Textbox (Default:
0%)
• Type in desired rate %
This parameter determines LL master requested firing rate below the minimum firing rate for drop stage condition to
occur.
5-23.5 To Change Add Stage Interstage Delay
Configure → Lead Lag Master Configuration → Advanced Setting → Drop Stage → Interstage Delay Textbox
(Default: 0m30s)
• Type in desired time
This parameter specifies the minimum time that the stager waits before dropping a stage.
5-24 Miscellaneous Configuration
5-24.1 To Change Alarm Silence Time
Configure → System Configuration → Alarm Silence Time Textbox (Default: 0m0s)
• Type in desired time between 0 to 5 minutes
5-24.2 To Enable Or Disable Pre-Ignition Interlock
Configure → Burner Control Interlocks → PII Enable Textbox (Default: Disabled)
• Select Enable to enable Pre-Ignition Interlock
• Select Disable to disable Pre-Ignition Interlock
5-24.3 To Change Anti Short Cycle Time
Configure → System Configuration → Anti Short Cycle Textbox (Default: 0m0s)
• Type in desired time between 0 to 5 minutes
Whenever the burner is turned off due to no demand the anti-short cycle timer is started and the burner remains in a
Standby Delay condition waiting for this time to expire. Does not apply, however, to recycle events or DHW demand.
5-24.4 To Change Burner Name
Configure → System Identification & Access → Boiler Name Textbox (Default: Boiler 1)
This parameter allows each boiler to have a unique name of up to 20 characters.
5-24.5 To Change Installation Data
Configure → System Identification & Access → Installation Textbox (Default: Atlas)
The installer may edit this parameter to provide installation information of up to 20 characters.
5-24.6 To Change Temperature Units
To Next Page
