The bubble level is provided to check the inclination angle of the mount during
installation. Wider holes ensure that the casing is correctly installed, even if
there are errors during installation.
Case C (260) and Case D (430) have battery holders at the bottom of the casing
to prevent accidental dislodgement. The holding stripe for securing the battery
is included with Case D (430).
Case D (430) has sixteen slots for plastic holders for Fibra modules installation.
Holders are available in two versions:
Installing the hub in Case D (430) does not meet the Grade (EN 50131) requirements.
The compliant version will be available soon.
There are four Module Holder (type A) in the complete set. Additional holders
and Module Holder (type B) are sold separately.
doesn’t require holders for installation.
Selecting the installation site
It is advisable to choose an installation site where Case is hidden from prying
eyes — for example, in the pantry. This will help reduce the likelihood of the
system sabotage. Note that the device is intended for indoor installation only.
The Case installation site must comply with the recommendations for mounting
the devices installed in the casing.
Follow these recommendations when designing the Ajax system project for an
object. The system should be designed and installed by professionals. The list
Module Holder (type A) for , ,
attachment;
LineSplit Fibra LineProtect Fibra MultiRelay
Fibra
Module Holder (type B) — for the board.Hub Hybrid
LineSupply Fibra
