AJAX Fire Protect User Manual

Tech Specs
Smoke-sensitive element
Photoelectric sensor
Temperature sensitive element
Thermocouple
Sound notification volume
85 dB at a distance of 3 m
Alarm threshold at the
temperature
+59°С ±2°С
Tamper protection
Yes
Frequency band
868.0 – 868.6 MHz or 868.7 – 869.2 MHz depending on the
region of sale
Compatibility
Operates independently or with Hub, Hub Plus, Hub
2, ReX, ocBridge Plus, uartBridge
Maximum RF output power
Up to 20 mW
Radio signal modulation
GFSK
Radio signal range
Up to 1,300 m (any obstacles absent)
Power supply
2 × CR2 (main batteries), CR2032 (backup battery), 3 V
Battery life
Up to 4 years
Operating temperature range
From 0°С to +65°С
Operating humidity
Up to 80%
Overall dimensions
132 × 132 × 31 mm
Weight
220 g

AJAX Fire Protect Specifications

General

Smoke-sensitive element	Photoelectric sensor
Temperature sensitive element	Thermocouple
Tamper protection	Yes
Compatibility	Operates independently or with Hub, Hub Plus, Hub 2, ReX, ocBridge Plus, uartBridge
Sound notification volume	85 dB at a distance of 3 m
Alarm threshold at the temperature	+59°С ±2°С
Operating temperature range	From 0°С to +65°С
Operating humidity	Up to 80%
Frequency band	868.0 – 868.6 MHz or 868.7 – 869.2 MHz depending on the region of sale
Radio signal modulation	GFSK
Radio signal range	Up to 1, 300 m (any obstacles absent)
Maximum RF output power	Up to 20 mW
Power supply	2 × CR2 (main batteries), CR2032 (backup battery), 3 V
Battery life	Up to 4 years

Weight and Dimensions

Overall dimensions	132 × 132 × 31 mm
Weight	220 g
