AJAX Hub 2 Plus User Manual



Malfunction
Click
to open the list of Hub 2 Plus
malfunctions.
The �eld appears only if a malfunction is detected
Cellular Signal Strength
Shows the signal strength of the mobile network
for the active SIM card. We recommend installing
the hub in places with the signal strength of 2-3
bars. If the signal strength is weak, the hub will
not be able to dial-up or send an SMS about an
event or alarm
Battery Charge
Battery level of the device. Displayed as a
percentage
Lid
Status of the tamper that responds to hub
dismantling:
External power supply connection status:
1.

Devices


2.

How battery charge is displayed in
Ajax apps

— the hub lid is closed

— the hub removed from
SmartBracket holder
What is a tamper?

AJAX Hub 2 Plus Specifications

General

Maximum Number of Devices	200
Maximum Number of Cameras	100
Maximum Number of Users	200
Battery Backup	Up to 15 hours
Operating Temperature Range	-10°C to +40°C
Maximum Number of Security Groups	25
Humidity	Up to 75%
Communication Channels	Ethernet, Wi-Fi
Power Supply	110-240 V AC
Dimensions	163 x 163 x 36 mm
Communication Range	Up to 2, 000 m in open space
Radio Frequency Bands	868.0–868.6 MHz
Supported Devices	Motion detectors, door/window sensors, sirens
Encryption	AES encryption
Firmware Updates	Over-the-air (OTA)
