Alarm signals processing mode Pulsed or bistable
Main power supply 110–255 V, 50/60 Hz
Backup power 12 V DC
Supported battery type
12 V battery with a full charge cycle of up to 30
hours. The maximum battery size for installation
in the body is 150 × 64 × 94 mm
Recommended battery type 12V battery with a capacity of 4 or 7 A⋅h
Detector power supply
12 V DC, up to 1 A total for all detector power
supply outputs
Protection against dismantling Tamper
Radio signal frequency band
868.0–868.6 MHz or 868.7–869.2 MHz,
depending on the sales region
Compatibility
Operates only with all Ajax , and
Maximum RF output power Up to 7.29 mW (25 mW limit)
Radio signal range Up to 2,000 m (any obstacles absent)
Operating temperature range From −10°С to +40°С
Operating humidity Up to 75%
Dimensions 196 × 238 × 100 mm
Weight 805 g
Complete Set
hubs range
extenders
1. MultiTransmitter
2. Power cable
3. 12 V battery connection cable
4. Installation kit
5. Body
. Quick Start Guide
