The body allows mounting the integration module on a vertical surface.
In order to install a module:
After installation, be sure to check the MultiTransmitter tamper status in the Ajax app.
Do not install the integration module:
Maintenance
1. Secure the body to the surface with bundled screws using at least two fixing
points. In order for the integration module tamper to respond to a dismantling
attempt, be sure to fix the body at the point with the perforated section.
2. Install the MultiTransmitter card into the body on the racks.
3. If available, connect a backup battery. Don’t connect external power supply!
We recommend using a 12 V battery with a capacity of 4 or 7 A⋅h. For such batteries,
special racks in the body are designed. You can also use similar batteries of a different
capacity, of matching size, with the maximum full charge time of no more than 30
hours. The maximum battery size for installation in the body is 150 × 64 × 94 mm.
4. Connect wired detectors and devices to the integration module. Turn on the
integration module.
5. Install the lid on the body and secure it with the bundled screws.
Outdoors.
Near metal objects and mirrors causing radio signal attenuation or screening.
Inside premises with temperature and humidity outside the permissible limits.
At a distance of less than 1 meter from the hub.
