Tests are available in the device settings menu (Ajax app
→
Devices
→
MultiTransmitter
→
Settings ):
Selecting MultiTransmitter placement
The placement of the integration module determines its distance from the hub and
the presence of obstacles between them that impede the passage of the radio
signal: walls, inter-floor constructions, or large-sized objects located in the room.
Be sure to check the signal strength at the installation site. If the signal strength is low (a
single bar), we cannot guarantee a stable operation of the security system! At the very least,
relocate the device as repositioning even by 20 cm can significantly improve the signal
reception.
If poor or unstable signal strength is still reported after the relocation of the device,
use the of the security system.
When choosing the installation location, consider the distance between the
integration module and wired devices or detectors — the cable length should be
sufficient for connection. The maximum length of the signal cable for connecting a
device or a detector is 400 meters (cable material is copper-plated aluminum,
cross-section is 0.22 mm²). The value may vary if a different type of cable is used.
No tests were conducted on other types of cables.
MultiTransmitter installation
Prior to mounting the integration module, ensure that you have selected the optimal location
and that it corresponds to this manual!
Jeweller Signal Strength Test
Attenuation Test
ReX radio signal range extender
