AJAX Relay User Manual

If using inductive or capacitive load, the maximum commutated current decreases to 3 A
at 24 V DC and to 8 A at 230 V AC!
Complete Set
Warranty
Warranty for the “AJAX SYSTEMS MANUFACTURING” LIMITED LIABILITY
COMPANY products is valid for 2 years after the purchase.
If the device does not work correctly, you should first contact the support
service — in half of the cases, technical issues can be solved remotely!
Technical support:
1. Relay
2. Connecting wires — 2 pcs
3. Quick Start Guide
The full text of the warranty
User Agreement
support@ajax.systems

AJAX Relay Specifications

General

Actuating element	Electromagnetic relay
The service life of the relay	200, 000 switchings
Operating modes	Pulse and bistable
Pulse duration	0.5 to 255 seconds
Parameter control	Yes (voltage)
Supply voltage range	7 – 24 V (DC only)
Voltage protection	Yes, min — 6.5 V, max — 36.5 V
Maximum load current*	5 A at 36 V DC, 13 A at 230 V AC
Maximum current protection	No
Device energy consumption	Less than 1 W⋅h
Frequency band	868.0 – 868.6 MHz or 868.7 – 869.2 MHz depending on the region of sale
Effective radiated power	3.99 mW (6.01 dBm), limit — 25 mW
Modulation of the radio signal	GFSK
Maximum distance between the device and the Hub	Up to 1000 m (any obstacles absent)
Communication ping with the receiver	12 – 300 sec (36 sec default)
Compatibility	Operates only with all Ajax hubs, and range extenders
Shell protection rating	IP20
Operating temperature range	From 0°С to +64°С (ambient)
Max. temperature protection	Yes, over 65°C at the place of installation or over 85°C inside the Relay
Operating humidity	Up to 75%

Weight and Dimensions

Dimensions	39 × 33 × 18 mm
Weight	25 g
