AJAX Relay User Manual

The device does not require maintenance.
Tech Specs
Actuating element Electromagnetic relay
The service life of the relay 200,000 switchings
Supply voltage range 7 – 24 V (DC only)
Voltage protection Yes, min — 6.5 V, max — 36.5 V
Maximum load current* 5 A at 36 V DC, 13 A at 230 V AC
Operating modes Pulse and bistable
Pulse duration 0.5 to 255 seconds
Maximum current protection No
Parameter control Yes (voltage)
Device energy consumption Less than 1 W⋅h
Frequency band
868.0 – 868.6 MHz or 868.7 – 869.2 MHz
depending on the region of sale
Compatibility
Operates only with all Ajax , and
Effective radiated power 3.99 mW (6.01 dBm), limit — 25 mW
Modulation of the radio signal GFSK
Maximum distance between the device and the
Hub
Up to 1000 m (any obstacles absent)
Communication ping with the receiver 12 – 300 sec (36 sec default)
Shell protection rating IP20
Operating temperature range From 0°С to +64°С (ambient)
Max. temperature protection
Yes, over 65°C at the place of installation or
over 85°C inside the Relay
Operating humidity Up to 75%
Dimensions 39 × 33 × 18 mm
Weight 25 g
hubs range
extenders

AJAX Relay Specifications

General

Actuating element	Electromagnetic relay
The service life of the relay	200, 000 switchings
Operating modes	Pulse and bistable
Pulse duration	0.5 to 255 seconds
Parameter control	Yes (voltage)
Supply voltage range	7 – 24 V (DC only)
Voltage protection	Yes, min — 6.5 V, max — 36.5 V
Maximum load current*	5 A at 36 V DC, 13 A at 230 V AC
Maximum current protection	No
Device energy consumption	Less than 1 W⋅h
Frequency band	868.0 – 868.6 MHz or 868.7 – 869.2 MHz depending on the region of sale
Effective radiated power	3.99 mW (6.01 dBm), limit — 25 mW
Modulation of the radio signal	GFSK
Maximum distance between the device and the Hub	Up to 1000 m (any obstacles absent)
Communication ping with the receiver	12 – 300 sec (36 sec default)
Compatibility	Operates only with all Ajax hubs, and range extenders
Shell protection rating	IP20
Operating temperature range	From 0°С to +64°С (ambient)
Max. temperature protection	Yes, over 65°C at the place of installation or over 85°C inside the Relay
Operating humidity	Up to 75%

Weight and Dimensions

Dimensions	39 × 33 × 18 mm
Weight	25 g
