AJAX Relay User Manual

Please note that deactivated device will save
it’s current state (active or inactive)
Unpair Device
Disconnect Relay from a hub and delete its
settings
Voltage protection — the contact will open when the voltage exceeds the limits
of 6.5–36.5 V.
Temperature protection — the contact will be opened when the temperature
threshold of 85°С inside Relay is reached.
Indication
The Relay light indicator can light green depending on the device status.
When not paired with the hub, the light indicator blinks periodically. When the
functional button is pressed, the light indicator lights up.
Functionality Testing
The Ajax security system allows conducting tests for checking the functionality
of connected devices.
The tests do not start immediately but within a period of 36 seconds when using
default settings. The test time start depends on the settings of the detector ping
interval (the Jeweller menu in the hub settings).
Installation of the Device
Regardless of the type of electrical circuit, only a qualified electrician should install
Relay.
Jeweller Signal Strength Test

AJAX Relay Specifications

General

Actuating element	Electromagnetic relay
The service life of the relay	200, 000 switchings
Operating modes	Pulse and bistable
Pulse duration	0.5 to 255 seconds
Parameter control	Yes (voltage)
Supply voltage range	7 – 24 V (DC only)
Voltage protection	Yes, min — 6.5 V, max — 36.5 V
Maximum load current*	5 A at 36 V DC, 13 A at 230 V AC
Maximum current protection	No
Device energy consumption	Less than 1 W⋅h
Frequency band	868.0 – 868.6 MHz or 868.7 – 869.2 MHz depending on the region of sale
Effective radiated power	3.99 mW (6.01 dBm), limit — 25 mW
Modulation of the radio signal	GFSK
Maximum distance between the device and the Hub	Up to 1000 m (any obstacles absent)
Communication ping with the receiver	12 – 300 sec (36 sec default)
Compatibility	Operates only with all Ajax hubs, and range extenders
Shell protection rating	IP20
Operating temperature range	From 0°С to +64°С (ambient)
Max. temperature protection	Yes, over 65°C at the place of installation or over 85°C inside the Relay
Operating humidity	Up to 75%

Weight and Dimensions

Dimensions	39 × 33 × 18 mm
Weight	25 g
