4-3. Start-up
1) Connecting of the unit
a) Connect the exposure switch into a female connector marked 'exposure
switch' on the rear cover.
b) Insert the line voltage input plug into a grounded wall socket.
WARNING
Verify the power switch is OFF before inserting of the plug.
Do not touch the plug with wet hands to prevent electric shock when
power is activated.
2) Switching the unit ON
Turn on the power switch on the rear cover.
After a few seconds, the initialization routine will run and display initial
data.
Initial display data : 80 kV, 3.0 mAs, 0.1sec.
NOTE
If initial display data is not displayed after power switch ON, turn off
the power switch and turn on it again after a few seconds.
-------------------------------------------------------------
AJEX240H / Operating instructions -19-
AXR-240H-MN01 (E) / Rev. 03
