4-6. Setting the exposure parameters
Set the desired kV and mAs values.
NOTE
Set the kV value first, then the mAs value is changed accoring to kV
setting value.
1) kV
Set the kV value using kV △,▽ key.
☞ Refer to page 14, 3-5. Overview of operating elements
2) mAs
Set the mAs value using mAs △,▽ key.
☞ Refer to page 14, 3-5. Overview of operating elements
NOTE
AJEX240H will automatically limit the range of possible exposure
parameters to ensure that the X-ray tube is not overloaded.
The following settings are permitted : 40kV to 120kV
0.4mAs to 120mAs
☞ Refer to page 26, Table 1. Exposure parameters & cool-down period
-------------------------------------------------------------
AJEX240H / Operating instructions -21-
AXR-240H-MN01 (E) / Rev. 03
