17
ACVDS727
Memory card playback
Trouble Action
No playback Memory card is not installed or installed incorrectly.
Insert memory card into slot.
DVD/CD in disc compartment. Remove DVD/CD
from disc compartment.
Technical data8.
DVD player
Parameter Value
Voltage 12 V
DC
Input voltage 100 ~ 240 V
AC
/ 50 ~ 60 Hz
Power consumption < 10 W
Max. power output 2 x 1 W (RMS)
USB connection USB 2.0 compatible
Flash memory connection SD/MMC/MS
Dimensions (W x H x D) 165 x 41 x 204 mm
Weight 700 g
Disc output
Parameter Value
Laser type Semiconductor
Signal/noise ratio > 80 dB
Wow and flutter Below the limit of the appliance
Frequency response 20 Hz - 20 kHz (1 dB)
TV system PAL/NTSC
Region code 2
Output Terminals
Parameter Value
Analog audio 1.4 Vrms (1 kHz, 0 dB)
