Other Useful Information (Cont.)
Technical specifications
The external static pressure of the air conditioner is 0Pa for all models.
Model Number
AK-T70R32
Capacity
Cooling 7300W
Heating 8000W
Current
Cooling 8.2A
Heating 9.4A
Rated Current (AS/NZS 60335)
Cooling 13.5A
Heating 14.5A
Power Input
Cooling 1800W
Heating 2100W
Rated Power Input (AS/NZS 60335)
Cooling 2800W
Heating 2900W
Room size suitability 35–50m
2
Rated Voltage and Frequency 220–240V ~, 50Hz
Ingress Protection Outdoor Unit IPX4
Max. Pressure
Discharge 3.7MPa
Suction 1.2MPa
Noise (SPL)
Indoor Unit 51dB(A)
Outdoor Unit 62dB(A)
Refrigerant Type
Type R32
Quantity 1420g
Indoor Airflow Volume
Cooling 1330m
3
/h
Heating 1430m
3
/h
Net Weight
Indoor Unit 17kg
Outdoor Unit 59kg
Dimensions (mm)
Indoor Unit 1186 x 340 x 258
Outdoor Unit 975 x 433 x 808
