CONNECTING EXTERNAL DEVICES
Complete the connections as shown below.
Pr / Y / Pb connection requires an component cable, not included.
S-VIDEO connection requires an S-VIDEO cable, not included.
VIDEO connection requires an VIDEO cable, not included.
tnempiuqelanretxE
ton(elbaC
)dedulcni
ton(elbaC
)dedulcni
VTfotupniOEDIV-SoT
VT
V
t
T
on(elbaC
)dedulcni
To Component input of TV
MW ANT
Connect the audio output jack(s) or headphone jack of the external audio equipment to the
AUX IN jacks on the front panel of this system.
CONNECTION CABLES ARE NOT INCLUDED.
You may leave your external device permanently connected to this system if you wish.
It is not necessary to disconnect the external device in order to listen to the Tuner or CD
player in this system.
