BEFORE YOUR FIRST USE:
1. Remove the product from the box.
2. Remove any packaging from the product.
3. Please retain all packaging until you have checked and
counted all the parts and the contents against the parts
list.
4. Your appliance is now ready for normal use.
5. Dispose of the packaging in a responsible manner.
POWERING ON AND CHARGING THE BATTERY:
Before using this speaker for the first time fully charge the
battery.
1. Plug the micro USB end of the charging cable into the port
on the speaker. Plug the USB connector into a computer’s
USB port or a compatible AC wall adaptor.
2. The red LED will turn on to indicate the device is charging.
3. Once fully charged, the red LED will turn off. When the
Battery is low, approximately 2 hours of charging time is
needed to charge it fully.
4. While the unit has charge, or is charging via the Micro USB
port, flip the ON/OFF switch into the ON position to turn
the speaker on.
Note: The speaker can still be used while charging the battery,
but will take more time to fully charge.
USING BLUETOOTH:
1. Flip the ON/OFF switch to the ON position. The LED light
on the Volume knob will flash blue.
2. Turn on the Bluetooth feature on your external device and
look for “A58077”.
3. Select the speaker name and pair it with your device. If a
password is required, press “0000”.
4. Once you’re connected the LED light will stop flashing
indicating your device has successfully paired.
5. If pairing is unsuccessful, restart both devices and repeat
the steps above.
6. Use the media controls on the Control Panel to control
playback.
BASIC OPERATION:
• To turn the speaker on, slide ON/OFF switch to the right.
• The speaker will beep and a blue LED will flash quickly.
• The blue LED will blink slowly when playing music.
• The speaker will beep every 20 seconds when the battery
is low.
• To turn speaker off, slide the On/Off switch to the left.
INDICATOR LIGHT STATUS:
STATUS INDICATOR LIGHTS
Charging Red LED ON
Fully Charged LED OFF
Pairing Mode Blue LED will flash quickly
Connected to Bluetooth Device Blue LED ON
Playing Blue LED will flash slowly
USING THE CONTROLS:
1. ON/OFF – Turns the speaker on and off.
2. Skip Backward/Volume Down – Slide left and hold left to
decrease the volume. Slide left but do not hold to skip back
to the last track played.
3. Skip Forward/Volume Up – Slide right and hold to increase
the volume. Slide right but do not hold to slip forwards to
the next track.
4. Play/Pause – Plays or Pauses audio.
5. LED Light – Indicates when the speaker is charging, ready
for pairing via Bluetooth and when successfully paired with
an external device.
6. TF Card Input – Insert a TF card to play stored tracks.
HANDS FREE PHONE OPERATION:
• Press the ‘Play/Pause/Phone’ key to answer an incoming
call.
• To end a call press ‘Play/Pause/Phone’ Key.
ADDITIONAL MODES:
TF Card
• Press the ‘Play/Pause/Phone’ key to enter TF Card Mode to
access an inserted TF Card.
Radio
• Press the ‘Play/Pause/Phone’ key to enter the radio mode,
press again for FM radio.
• To change radio stations slide the ‘Play/Pause/Phone’ to
the left or right to locate a station.
• Clean the appliance with a soft, damp cloth. Never use
chemicals or hard abrasives.
• Keep this unit away from wet or damp surroundings.
• Store in a cool, dry place.
• The crossed out wheelie bin symbol on this item
indicates that this product needs to be disposed of in
an environmentally friendly way when it becomes of no
further use or has worn out.
• Contact your local authorities for details of where to take
the item for re-cycling.
IN THE BOX
INSTRUCTION MANUAL
SPEAKER
USB CABLE
2-IN-1 CABLE/MINI MICRO USB & AUX CONNECTOR
1. SPEAKER CONTROL
A) PLAY/PAUSE/PHONE/FM
B) SKIP BACK /SKIP FORWARD
2. DC/MICRO USB PORT
3. TF CARD
4. USB INPUT
5. LED INDICATOR
6. ON/OFF
1 2 3 64 5
PROBLEM POSSIBLE CAUSE SOLUTION
Low sound
level
Source (Tablet,
Mobile Phone,
Laptop, etc.) volume
too low.
Battery is dead.
Adjust the source
volume to your desired
level.
Charge the battery.
Sound
distorted
Battery is nearly
dead.
Charge the battery.
No sound
at all
Source (Tablet,
Mobile Phone,
Laptop) turned off.
Speaker turned off.
Volume turned down
source.
Media paused on
source.
Turn the source on.
Turn the speaker on.
Adjust volume source.
Play media from
source.
Turn the speaker on.
Adjust the volume
source.
Play media from the
source.
FEATURES AND CONTROLS USING YOUR APPLIANCE TROUBLESHOOTING CLEANING & MAINTENANCE
