Akai EWI5000 User Manual

11
24. Line Output: Use a 1/4" (6.35mm) TRS cable to connect this output to the input of a
keyboard amplifier, audio interface, speaker system, etc.
Important: The Line Out is a stereo output. If you are connecting to a mono input (like
those on most keyboard amplifiers, audio interfaces, etc.), use a TS cable instead of a
TRS cable.
25. USB Port: Use a standard USB cable to connect this port to an available USB port on
your computer. This connection will power the EWI5000 and charge its battery as well as
send MIDI messages to your computer.

Akai EWI5000 Specifications

General

Type	Electronic Wind Instrument
Connectivity	USB, Wireless
Battery	Rechargeable Lithium-Ion
Presets	100
Controls	Octave Rollers
Inputs	USB
Wireless	2.4 GHz
Fingering Modes	EWI, Saxophone, Flute, Oboe
Outputs	1/4" Audio Out, 1/8" Headphone Out
