Akai GX-630D

nn
16)
REC
MODE
P.C
BOARD(TE-5003)BLOCK
On
Parts
No.
Description
Q'ty
16-1
BZ647831
Rec.
Mode
P.C
Board
Comp.
(TE-5003)
1
16-D1
ED624903
Silicon
Diode
182473
1
16-SW3
ES640541
Push
SW.
2FT-0014FF1320
1
16-RL1
EP383321
Relay
TECK-36
DC22V
1000
ohm
t!
16L1,2
EO390622
Ferri
Inductor
FLOH
2204uH(K)
2
16-2
EZ640451
SW.
Shield
1
16-3
ZS379350
ISO
Screw,
pan
head
3x6
1
16-4
ZW516611
Nut
M3
1
16-5
ZW273802
Toothed
Lock
Washer
M3
1
17)
SPEED
SWITCH
P.C
BOARD
(TE-5001)
BLOCK
a
Parts
No.
Description
ty
Oo.
D 17.1 BA6 peed Switch Pe Board Com:
E-5001) 1
17-SW2 ES640552 Slide SW. SSA06207 1
17-L1
EO379923
Ferri
Inductor
FL7H
8.2
MH(J)
2
17-2
MZ640618
Equalizer
Bracket
1
17-3
28432843
Screw,
pan
head
2,6x4
2
17-C1 EC250841 Mylar/C. 0.014F(J) SOWV
(Vert. Type) 2
Carbon Resistor Omitted
GX-630D/DB
Name
and
parts
number
of
Speed
Switch
P.C
Board
changed
as
follows:
Speed
Switch
P.C
Board
Comp.
TE-5001
BA647717
changed to
Speed
Switch
Block
Comp.
TE-5001
_BS647717
39
