2 ECS10716D Capacitor Electrolytic 100uF/16V D type 1 C103
SMD
2 FCN2T1002601 FCN Dual Touch Pitch=1.0mm 26P 1
J1 32
2 FCN2T1003003 FCN Dual Touch Pitch=1.0mm 30P 1
J16 33
2 ICAD5620BRJ IC converter AD5620BRJ-2REEL7 12BIT 1 U81
SOT23-8
2 ICLP2985-50DBVR IC LP2985-50DBVR SOT23-5 1 U82
2 ICSN74HCT125DR ICSN74HCT125DR 1 U83
2 ICYH101M10 IC (STM32F103RCT6+Program) LQFP-64 1 U1
3 ICSTM32F103RCT6 IC STM32F103RCT6 LQFP-64 1 (U1)
2 ICYH101M11 IC (LCMXO640C+Program) TQFP-100 1 U2
3 ICLCMXO640C IC LCMXO640C-3TN100C 1 (U2)
2 JK5KDJ03-5 MIDI Din Scoket 7P 90° 2 J80,81
2 JKDJ-0702B-020 DC Base 2.0MM 1 J84
2 PC12A016 Main PCB 2 Layer FR-4 1.6T 215*62MM 1 -
2 R002550 5(6&HPHQWȍ:',31 R116
2 RS000008J05 5(6ȍ60'1 R98
2 RS000010J03 5(6ȍ60'15 R1,25,53~59,93~97,99
2 RS000110F03 5(6ȍ60'1 R6
2 RS001K10F03 RES 1K 1% SMD 0603 8 R18,67~70,103~105
2 RS001M10F03 RES 1M 1% SMD 0603 1 R74
2 RS002210F03 5(6ȍ60'2 R8,9
2 RS004710F03 5(6ȍ60'2 R7,81
2 RS010010F03 5(6ȍ60'4 R2,4,24,80
2 RS010K10F03 RES 10K 1% SMD 0603 22 R11,13~17,22,76,77,85~92,101,107,108,110,111
2 RS011K10F03 RES 11K 1% SMD 0603 2 R48,49
2 RS01K510F03 RES 1.5K 1% SMD 0603 1 R114
2 RS022010F03 5(6ȍ60'3 R82~84
2 RS04K710F03 RES 4.7K 1% SMD 0603 1 R23
2 RS080610F03 5(6ȍ60'1 R60
2 RS100K10F03 RES 100K 1% SMD 0603 4 R66,102,106,109
2 RS11K810F03 RES 11.8K 1% SMD 0603 1 R64
2 RS15K810F03 RES 15.8K 1% SMD 0603 4 R44~47
2 RS1K3310F03 RES 1.33K 1% SMD 0603 1 R63
2 RS220K10F03 RES 220K 1% SMD 0603 1 R115
2 RS22K110F03 RES 22.1K 1% SMD 0603 1 R65
2 RS2K3210F03 RES 2.32K 1% SMD 0603 1 R71
2 RS33K210F03 RES 33.2K 1% SMD 0603 1 R73
2 RS3K3210F03 RES 3.32K 1% SMD 0603 4 R40~43
2 RS47K510F03 RES 47.5K 1% SMD 0603 3 R50~52
2 RS4K7510F03 RES 4.75K 1% SMD 0603 2 R61,62
2 RS820K10F03 RES 820K 1% SMD 0603 1 R112
2 RS82K510F03 RES 82.5K 1% SMD 0603 1 R72
2 RS8K0610F03 RES 8.06K 1% SMD 0603 1 R113
2 TE512540801 Pin Header 180° Pitch=2.54mm Single Row 1 J2
8Pin DIP
2 TE852542001 Connector 1 J5
2 XTM08000X3 Crystal 8MHZ 49US Fundamental 1 X1
1 TWPC12A01702 TOP PCB Assembly 1
2 PC12A017 TOP PCB 2 Layer FR-4 1.6T 145*397MM 1
2 TWPC12A017A01 TOP PCB Assembly 1 17
3 AL0-17-0103 RES Array 4X10K 1/10W 0603 9 R1,2,5,6,97,98,103,110,111
3 AL0-17-0221 RES ARRAY 4X220 1/10W 0603 3 R91,93,144
3 AL0-17-0470 RES Array 4X47 1/10W 0603 4 R7,92,145,146
3 AL2-49-0070 Diode BAV70 5 D2~4,7,9
3 AL2-51-4401 Transistor 2N4401 NPN SOT-23 (Transistor 1 Q14

Akai MAX25 Specifications

General

Mixer section	-
Product color	Red
Backlight buttons	Yes
Number of controls	3
Display type	LCD
USB version	2.0
USB ports quantity	1
Power supply type	AC
Minimum RAM	1 GB
Minimum processor	Pentium 4/Celeron/G4/G5 or faster
Minimum processor speed	1.5 GHz
Mac operating systems supported	Mac OS X 10.4 Tiger, Mac OS X 10.5 Leopard, Mac OS X 10.6 Snow Leopard, Mac OS X 10.7 Lion, Mac OS X 10.8 Mountain Lion, Mac OS X 10.9 Mavericks
Windows operating systems supported	Windows 7 Home Basic, Windows Vista Business, Windows XP Home
Bundled software	Includes Ignite™ music creation software with over 275 instrument sounds from AIR Music Technology.\\r \\r Ableton® Live Lite Akai Pro Edition software included.\\r \\r Included AkaiConnect software automatically maps to VST™ plugins.

Weight and Dimensions

Depth	81.2 mm
Width	434.05 mm
Height	329.82 mm
Weight	3300 g
