TECHNICAL SPECIFICATIONS
GENERAL
Display custom LCD w/ backlight
Dimensions (WxDxH) 308mm x 384mm x 64mm
Weight 2.5kg
Power
~100mA, 5V DC via USB
~1A, 6V DC via external adaptor
Number of Presets 30
MIDI output channels over USB 48 (16 channels x 3 ports)
MIDI output channels from 5-pin MIDI 16
Drum pads 16 (velocity and pressure sensitive)
Drum pad banks 4
Faders 8
360 degree knobs 8
Switches 8
Accessories
User’s manual
USB cable (1m)
CD-ROM disc
INPUTS/OUTPUTS
MIDI inputs 5-pin DIN x 1
MIDI outputs 5-pin DIN x 1
USB Slave connector x 1 (MIDI over USB)
DC IN 6V DC, 1A
CONTACT INFORMATION
Please visit the Akai Professional website (www.akaipro.com) regularly for additional information, news and
firmware upgrades for the MPD32.
For additional technical support:
EMAIL
: support@akaipro.com
TEL: 401.658.4032 (U.S)
