Akai MPD232 User Guide

13
Clock
Source: Determines whether MPD232 uses its Internal MIDI clock or refers to an External
clock (e.g., from a DAW).
SysEx
Send Program: The Program to be sent via SysEx. The available options are the individual
Program numbers or all Programs. Press the Data Dial to send the Program.
Utilities
Contrast: The display contrast. The available options are 0 to 99.
Save Globals
On this page, press the Data Dial to store your global settings. After Saving Globals flashes
on the display, the global settings are stored in MPD232’s internal memory.
Reset Globals
On this page, press the Data Dial to restore MPD232’s factory/default settings. After
Restoring flashes on the display, the factory/default settings have been restored.
OS
Version: MPD232’s current operating system information.
Boot ROM: MPD232’s current ROM read-only memory information.

Akai MPD232 Specifications

General

MIDI out	Yes
USB version	2.0
USB connector type	USB Type-B
USB ports quantity	1
Product color	Black
Number of drum pads	16
Number of mixer channels	8 channels
Current	1 A
Input voltage	6 V
Power supply type	USB
AC adapter included	No
Minimum RAM	1 GB
Minimum processor speed	1.25 GHz

Weight and Dimensions

Depth	254 mm
Width	422 mm
Height	48 mm
Weight	1900 g
