Akai TIMBREWOLF - Page 11

3 RS37K410F03 RES 37.4K 1% SMD 0603 1
R2
3 RS39K210F03 RES 39.2K 1% SMD 0603 1
R78
3 RS3K1610F03 RES 3.16K 1% SMD 0603 1
R62
3 RS3K3210F03 RES 3.32K 1% SMD 0603 2
R69,70
3 RS47K510F03 RES 47.5K 1% SMD 0603 11
R25,26,29,30,33,34,37,38,41,42,65
3 RS47R510F03 RES 47.5ȍ 1% SMD 0603 7
R7,10,16~18,20,76
3 RS49K910F03 RES 49.9K 1% SMD 0603 1
R67
3 RS4K7510F03 RES 4.75K 1% SMD 0603 1
R77
3 RS7K8710F03 RES 7.87K 1% SMD 0603 1
R57
3 SWSPPJ22ME04 Switch Push 2P2T Dual Row Lock 1
SW1
3 TE10201002 Connector(10P Socket) 1
J15
3 TE612001401 Connector Base 14P 180° 1
J16
3 TE612001602 Connector Socket 16P 1
J17
3 TR2SD2114KSM Transistor 2SD2114K NPN SOT-23 7
Q6~12
3 UHSQD105T-751 Common Inductor 700ȍ ±35% 10.3X8mm 1
L1
2 AL9-79-0716B01 Pitch PCB Assembly 1
3 TE622000302 Pin Header 90° Pitch:2.00mm Single Row 1
J1
3P DIP
3 VRR50202901 Potentiometer Rotary Volume:5k Shaft 1
P1
Length 293mm Single Row
1 BAAR-034 FOOT STAND 4
17
1 BAGL-55A CABLE CLIP 55L 3
1 BAPC-02H-B1 Holder 1
18
1 BAUWA-01 Washer 8
29
1 BC1015011050 Bubble Pad 1
1 CN0320004501 Flat Cable Multicolored 3P Pitch 2.0mm 1
26
1 CN1420001006 Flat Cable 14P Pitch:2.0mm Single row 1
27
Length 100mm Female/Female
1 LAC22AKA400 Label 1
1 LAC54AKA406 Safety Label 1
1 LAC62AKA401 Bar Code Label(CODE 39) 0.5
1 LAC62AKA402 Bar Code Label(GTIN14) 0.5
1 LAC67MAR681 Label(Circle Limpid) 4
1 LAC67YAH261 Label ij8mm Green 1
1 MT11044183 Holder Screw 1
19
1 MT1105508 FIXED HOLDER(10MM) 6
9
1 MT1504461 Standoff 3
23
1 MT153002102 Top Panel Paint/Print 1
4
1 NM1104412 VELVET CARPET 5
28
1 NP607MAR115 Name Plate 1
21
1 PASD3AKA11 Packing Assembly 1
2 AL7-51-0226-M Safety Manual 1
2 CGASD3310AKA03 Gift Box 1
2 CTASD3513AKA02 Shipping Carton 0.5
2 OPASD3AKA11 Quick Instruction Book 1
2 PE230370402B07 Poly Bag 230*370mm 1
2 PLASD301 Poly foam(Left) 1
2 PLASD302 Poly foam(Right) 1
2 PUAD2501 EPE FOAM 1
2 SD890890 Soft Sheet 1
1 PT1510611301 Knob Print 1
2
2 PT15106113 Knob 1
1 PT15106121 Knob 8
5
