Akai TIMBREWOLF - Bill of Materials (BOM)

ASD3AKA11 BOM
LEVEL
P/N DESCRIPTION QTY
REF
0
ASD3AKA11 ASD3 AC100-240V USA 0
1 AL7-10-1215 Switching ADAPTOR(UL/JIS) DC12V/2A 1
1
AL9-79-071501 Main PCB Assembly 1
10
2 AL0-17-0272 RESISTOR 2
R91,152
2
AL0-17-2470 RES ARRAY 4X47 1/16W 0402 2
R450,503
2 AL1-60-2222 Ecap 22UF/16V SMD-B 7
C1~4,31,134,136
2
AL2-51-4401 Transistor 2N4401 NPN SOT-23 (Transistor 32
Q1~8,10,12,14,16,25~28,37~48,53,55
MMBT4401LT1 NPN SOT-23)
Q57,59
2
AL2-51-4403 Transistor 2N4403 PNP SOT-23 16
Q29~36,49~52,54,56,58,60
2 AL9-40-0715 Main PCB 4-Layer FR-4 384x178mm 1
-
2
BALE48207-5 LED Holder(7.5mm) 8
D11,12,21~26
2 BALED3X7C LED Holder(7mm) 18
(LED1~18)
2
CS100J5003NPO CCAP SMD 10pF/50V 5% 0603 NPO 2
C30,256
2 CS101J5003NPO CCAP SMD 100pF/50V 5% 0603 NPO 18
C15,21,23,25,27,86~89,150~153
C216~219,240
2 CS102J5003X7R CCAP SMD 1nF/50V 5% 0603 X7R 26
C17~20,46~49,124,126,128,132,139
C141,143,186,220,233,234,236,241
C242,248~251
2 CS103J5003X7R CCAP SMD 0.01uF/50V 5% 0603 X7R 12
C50~53,66,67,83,84,244~247
2
CS104K5003X7R CCAP SMD 0.1uF/50V 10% 0603 X7R 112
C5~14,22,24,26,28,29,36~45,58,62,76
C85,90~107,114,125,127,129~131,133
C135,140,142,144,158~173,184,187
C200~205,207~215,221~223,228~232
C235,237~239,243,253~255,257~261
2 CS105K1003X5R CCAP SMD 1uF/10V 10% 0603 X5R 4
C193,195,197,199
2
CS150J5003NPO CCAP SMD 15pF/50V 5% 0603 NPO 1
C16
2 CS152J5003NPO CCAP SMD 1500PF/50V 5% 0603 NPO 4
C178~181
2
CS180J5003NPO CCAP SMD 18pF/50V 5% 0603 NPO 2
C182,183
2 CS225K1605X7R CCAP SMD 2.2uF/16V 10% 0805 X7R 4
C174~177
2
CS332J5003NPO CCAP SMD 3.3nF/50V 5% 0603 NPO 8
C145~148,154~157
2 CS392J5005NPO CCAP SMD 3.9nF/50V 5% 0805 NPO 8
C77~80,108~111
2
CS472J5003X7R CCAP SMD 4.7nF/50V 5% 0603 X7R 4
C112,113,115,116
2 CS474K1603X7R CCAP SMD 0.47uF/16V 10% 0603 X7R-RoHS 1
C68
2 CS475K0603X5R CCAP SMD 4.7uF/6.3V 10% 0603 X5R 3
C81,82,185
2
CS683K5005X7R CCAP SMD 0.068uF/50V 10% 0805 X7R 4
C224~227
2 DIEN1N4148WSM Diode SMD 31
D4,9,10,28~39,44~55,57~60
2
DISDBAT54CSM Zener Diode BAST54C 4
D40~43
2 ECS33550B Capacitor Electrolytic SMD 3.3UF/50V 4
C192,194,196,198
2
ECS33716FLE ECAP 330uF/16V 8*10.2mm SMD LOW ESR 3
C137,138,149
2 ECS47650D Capacitor Electrolytic 47uf/50v D Type 4
C188~191
2
IC74AHC245PW IC SN74AHC245PWR Octal Bus Transceivers 5
U42,51,54,57,62
Witch 3-State Output TSSOP20
2 IC74LVC574APWR IC SN74LVC574APW TSSOP-20 10
U30~32,52,53,56,58~61
2 ICLM317 IC LM317 1.5A SOT-223 1
U29
2 ICLM358 IC LM358 DUAL OP-AMP SOIC-8 5
U17,19,21,23,55
2 ICLM393DR IC OPA LM393DR SOIC-8 8
U9~12,33,35,37,39
2 ICNJM13600M ICNJM13600M DMP16 4
U18,20,22,24
2 ICNJM4580CG ICNJM4580CG SOP8 21
U1~8,13,34,36,38,40,43~50
2 ICYH103M10 IC(STM32F103VBT6+Program)LQFP-100 1
U41
