2 RS1K1810F03 RES 1.18K 1% SMD 0603 4
R48,51,54,57
2 RS1K2410F03 RES 1.24K 1% SMD 0603 4
R422~425
2 RS200K10F03 RES 200K 1% SMD 0603 4
R383,385,387,389
2 RS22R110F03 RES 22.1ȍ 1% SMD 0603 2
R221,222
2 RS249K10F03 RES 249K 1% SMD 0603 8
R346,349,352,355,371,374,377,380
2 RS24K910F03 RES 24.9K 1% SMD 0603 16
R347,348,350,351,353,354,356,357,366~369
R460,466,472,478
2 RS2K4910F03 RES 2.49K 1% 1/10W SMD 0603 4
R459,465,471,477
2 RS33K210F03 RES 33.2K 1% SMD 0603 4
R30,33,36,39
2 RS33R210F03 RES 33.2 1% SMD 0603 8
R62~69
2 RS3K0110F03 RES 3K01 1/10W SMD 1/10W 0603 4
R126,127,132,133
2 RS3K3210F03 RES 3.32K 1% SMD 0603 8
R112,115,228,231,408~411
2 RS402K10F03 RES 402K 1% SMD 0603 4
R116,562,564,566
2 RS499K10F03 RES 499K 1% SMD 0603 4
R190,198,206,214
2 RS49K910F03 RES 49.9K 1% SMD 0603 8
R71,73,75,77,142,146,571,573
2 RS4K0210F03 RES 4K02 1% SMD 0603 12
R58~61,78~81,83,85,87,89
2 RS4K7510F03 RES 4.75K 1% SMD 0603 8
R438,440,442,444,446~449
2 RS4K9910F03 RES 4.99K 1% SMD 0603 41
R10,11,13,15,17,19,21,23,25,47,50,53
R56,158,160,166,168,174,176,182,184
R191,195,199,203,207,211,215,219,456
R458,462,464,468,470,474,476,493,496
R499,502
2 RS51R110F03 RES 51.1ȍ 1% SMD 0603 8
R192,193,200,201,208,209,216,217
2 RS6K9810F03 RES 6.98K 1% SMD 0603 4
R27,41~43
2 RS86K610F03 4
R108,109,118,119
2 SWDC11B2020484 Switch Rotatiomalzopulse 20.1mm 1
ENC1
2 SWEVQ11L04M Switch Tact 4.3mm 160g Horizontal DIP 31
S5~35
2 SWSSE22E07-7.5K Switch Slide Single Row 180° 4
S1~4
2 SWSSV-23D09N-55 Switch Slide 2P 3T 1
SW2
2 TE622000302 Pin Header 90° Pitch:2.00mm Single Row 1
J6
3P DIP
2 TE622001001 Terminal 10P 90° 1
J5
2 TE622001401 Connector 14P 1
J2
2 TE622001603 Pin Header 90° Pitch:2.0mm Single Row 1
J1
6Pin DIP
2 TE952541601 40P Terminal 1
J4
2 TR2SD2114KSM Transistor 2SD2114K NPN SOT-23 4
Q9,11,13,15
2 VRR10301535 Potentiometer potary volume:10K 1B shaft 13
P1~4,9,11,13,15,17,19,21,23,25
Length:15mm single unit
2 VRR10301536 Potentiometer Rotary 10KB Shaft Length: 4
P5~8
15mm Single-unit Center Click
2 VRR10401506 Potentiometer Rotary 100KB Shaft Length: 1
P10
15mm Single-unit
2 VRR20301506 Potentiometer Rotary 20KB Shaft Legnth: 4
P12,14,16,18
15mm Single-unit
2 VRR50401501 Potentiometer Rotary 500KB Shaft Length: 4
P20,22,24,26
15mm Dual-unit
2 XTM08000X6F1 Crystal 8MHZ 49US SMD Fundamental 1
X1
1 AL9-79-071601 I/O PCB Assembly 1
2 AL9-40-0716 I/O PCB 2Layer FR-4 348x121mm 1
2 AL9-79-0716A01 I/O PCB Assembly 1
3 AL2-50-4149 Diode Single 1N4148 100V 200mA SOT-23 7
D8~14
3 AL2-51-4401 Transistor 2N4401 NPN SOT-23 (Transistor 10
Q1~5,15,17,19~21
