6 Specifications
Type: pre-polarized condenser microphone
Frequency range: 20 Hz to 20,000 Hz
Polar pattern: cardioid
Sensitivity at 1 kHz: 7 mV/Pa (-43 dBV re 1 V/Pa)
Impedance: 200
Recommended load impedance: >2000
Max. SPL for 1%/3% THD: 126/130 dB SPL
Equivalent noise level: 33 dB (A) (to IEC 60268-4)
Power requirement: 9 to 52 V universal phantom power
Current consumption: approx. 2 mA
Connector: 3-pin male XLR
Finish: matte black
Size: length: 79 mm (3.1 in.); dia.: 19 mm (0.7 in.)
Net/shipping weight: 32 g (1.1 oz.) / 192 g (6.8 oz.)
This product conforms to the standards listed in the Declaration of
Conformity. To order a free copy of the Declaration of Conformity, visit
http://www.akg.com or contact sales@akg.com
Frequency Response Polar Diagram
C 430
