Reference Handheld Dynamic Microphone
SPECIFICATIONS
Polar pattern Supercardioid
Frequency range 70 to 20,000 Hz
High pass Filter 80 Hz, always active
Sensitivity 2.6 mV/Pa (-52 dBV)
Max. SPL for 1%/3% THD 147 / 156 dB SPL
Equivalent noise level 18 dB-A (IEC 60268-4)
Signal/noise ratio (A-weighted) 76 dB
Impedance / load Impedance 600 ohms, 2000 ohms
Humbucking coil Integrated on capsule
Connector 3-pin XLR
Finish Matte gray blue
Dimensions Length: 185.2 mm (7.3 in.);
Diameter: 51 mm (2 in.)
Net / shipping weight 340 g (12 oz.) / 655 g (1.45 lbs.)
Standard accessories Padded cylindrical zip case, SA 61, replacement inner windscreen
Item numbers D 7: 3139Z00010
D 7 WL 1*: D 7 capsule for WMS 4000 and 4500
*available summer 2008
