1. INTRODUCTION
The following is intended to provide the basic instructions for installation, operation and maintenance of
the Akron Brass Style 6047 Wireless Remote Controller, and to assist in attaining the best possible
performance from the unit. IMPORTANT: PLEASE READ THESE INSTRUCTIONS CAREFULLY, NOTE
THE SAFE OPERATIONAL REQUIREMENTS, WARNINGS, AND CAUTIONS. USE THIS PRODUCT
CORRECTLY, AND WITH CARE FOR THE PURPOSE FOR WHICH IT IS INTENDED. FAILURE TO DO
SO MAY CAUSE DAMAGE, OR PERSONAL INJURY, AND WILL INVALIDATE THE WARRANTY!
2. PRODUCT RATINGS
• Input Power Requirements: 3.6V via Akron Brass Batteries P/N 60470008. Unit has space for
two batteries, but only one battery is needed to power the Wireless Remote Controller.
• Controller Power Consumption: Off Mode (5 mW), Idle Mode (125 mW), Operating Mode (1.5 W)
• Battery Life: 12 continuous hours per battery, or 24 hours total, when operating at full power when
LED intensity is at factory default setting.
• RF Radio
o Output Power: 8dBm for 2.4GHz and 24dBm for 900 MHz, both meet FCC part 15
requirement for license free operation
o Operating Frequency: 2.4 GHz or 900 MHz (see label for frequency)
o FCC ID: MCQ-XBEE3 for 2.4 GHz, or MCQ-XB900HP for 900 MHz
o Operational range: 250 feet (76.2m) for 2.4GHz and 300 feet (91.44m) for 900MHz
outside with clear line of sight – no obstacles
• WiFi Radio
o Output Power: 187mW
o Operating Frequency: 2.4 – 2.5 GHz
o FCC ID: 2AC7Z-ESPWROOM02U
o Protocol 802.11 b/g/n
o Operational range: 10 feet (3.048m)
• Dimensions: 6-11/32” (16.1cm) L x 5” (12.7cm) W x 2-3/8” (6.03cm) H
• Weight: 1lb (0.45kg); 1.5lbs (0.68kg) with batteries
• Environmental Conditions:
o Operating Temperature: -20°C (-4°F) to 50°C (122°F)
o Storage Temperature: -10°C (14°F) to 30°C (86°F) Batteries; -20°C (-4°F) to 50°C
(122°F) Wireless Remote Controller
o Suitable for use up to 6,562 feet (2,000 meters) elevation
o Pollution Degree 2
o Relative humidity range 60 ± 25% for temperatures up to 50°C
o Ingress protection: IP66 equivalent
3. PRODUCT WARNINGS
