SIP Video Phone
LAN
PoE
E12S/W
PoE
PC (third party)
PoE
Hang the device on to the two square
hangers on the wall-mounting bracket,
then use the Torx wrench attached to
tighten the bottom of the device with
two M3x6 Torx head screws.
E12
The installation is completed.
Indoor Monitor
PON
E12N
Application Network Topology
Connect the wires to the interface of
the device as needed (for details,
refer to “Device Wiring”). After
arranging the wires, tighten the
wiring cover using four M3x4
crosshead screws to the device.
To Next Page
