10
GENERAL SPECIFICATIONS
x ACK2 boilers are reverse flame, 2 pass, wet back, cylindrical shell type,
hot water, liquid or gas fired, B
23
steel boilers.
x ACK3 boilers are LOW NO
x
, 3 pass, wet back, cylindrical shell type,
hot water, liquid or gas fired, B
23
steel boilers.
x They are manufactured and tested in accordance with TS EN 303-1, by
an ISO 9001-2000 registered company.
x They are economical and environmentally friendly.
x Compact design ensures easy transport into boiler rooms.
x The boilers have been specially designed and produced to perform efficient
combustion with both gas and liquid fuels.
x Boiler gas side pressure loss is well below the limited values in EN
standards.
x Economic ad safe heating system operation through optional boiler control
panels. Control Panel in Three Different Models: a) Standard Single stage
boiler control panel b) Standard Two stage boiler control panel c) Weather
Compensated Economy Panel.
x ACK2 boilers have 30 different capacities between 30.000-3.000.000 Kcal/
h (35 – 3488 kW) and standard working pressure is 3 bar for between
ACK2-30 / ACK2-180 capacities and 4 bar for ACK2-200 and aboves.
x ACK3 boilers have 15 different capacities between 80.000-1.000.000
Kcal/h. (93 – 1163 kW) and standard working pressure is 3 bar.
x Minimum heat loss with perfect insulation.
x Wide water galleries and the return water connection is from the back
bottom side provide excellent natural circulation and safe heat transfer.
x No additional intermediate flow pieces required. All necessary connections
are already on the boiler.
x They have low combustion chamber loading for clean combustion with
low nitrogen oxide emissions.
x Boiler front door can be opened in both directions, very useful in boiler
rooms with limited space.
