RCA L Version 2.0 3
The M&I Re-Coil-Away door contains the following parts:
(1) Header Assembly
Contains the curtain, operator
(2) Door Curtain
SBR, EPDM
(3) Side Frames
Painted steel
(4) Pneumatic Safety Edge
Self monitoring
(5) Drive System
Jack Shaft operator
(6) Safety Photocell
ADS Photocells – either reflective or thru-beam
(7) Springs
50,000 cycle
(8) Chains and sprockets
Size 60 chain
(9) Idler Barrel (not shown)
Helps guide the curtain into the side frames
(10) Hoods (Optional) (not shown)
Components
To Next Page
