1.7 Optional accessories
Intuitive attendant control
Swivel arm for the control unit
Opti-Box
Speed-Stop/Speed limit switch
Various joystick options
Various battery packs
Anti-tippers
Spoke cover
External charger socket
External On/Off switch
Bumper bar for the control unit
We recommend using only original accessories supplied by Alber.
The e-fix is designed in such a way that it performs best when using Alber original accessories. Alber GmbH shall not be liable for damage
to the product or accidents (e.g. fires) caused by a malfunction of non-original accessories or spare parts. The warranty does not cover
repairs for damage caused by malfunction of non-original accessories. Alber GmbH will, however, carry out such repairs for you at a charge.
1.8 The main elements at a glance
(please fold out overview drawing in document cover)
Wheelchair and e-fix wheel Battery and battery holder
Bracket on wheelchair 1 Handle 25
e-fix wheel 2 Info button 26
Viewing panel on the e-fix wheel 3 Capacity indication 27
Releasing device 4 Fault indication 28
Coupling ring 5 Socket for connecting the control unit,
Wheelchair parking brake 6 the attendant control and the charger 29
Battery holder 7 Insertion aid on the battery holder 30
Battery pack 8
Control unit 9 Charger
Wheel socket 10 Charger 31
Stub axle 11 Charger mains plug 32
Torque plug 12 Charger plug 33
Wheel receiver 13 LED display 34
Control unit
Joystick 14
On/off button close range lighting 15
On/off button menu function 16
On/off button warning signal 17
Display 18
On/off button entire system 19
Immobiliser 20
Lighting (beneath the control unit) 21
Rotary switch for preselecting the speed 22
Plug with connection cable 23
Immobiliser key 24
This operating manual is available for download on our website www.alber.de.
If you require a version that is written in a larger font,
contact our Alber Service Center.
