S-Meter / Power
There is a bar graph display for the signal strength of the received signals. More bars = higher
input signals. A strong signal with S 9 + 30 will show full deflection. The bar graph is used for
Power meter as well. 4 Watt = full deflection, 1 Watt = 2 or 3 bars.
Suelch Adjustment
Especially in FM the background noise will disturb on free channels. With the squelch control
SQ you can suppress this noise by carefull adjustment of the SQ potentiometer. You can also
suppress weak signals or signals, which are far away and which You may not wish to receive.
SQ to left position: All signals can be heard
SQ turned more clockwise: Signals must be stronger to open the squelch
Best setting to highest sensitivity:
- Go to a free channel without any signal
- Turn
SQ
slowly and carefully so much to the clockwise position, that the
background noise just disappears.
Now the speaker will suppress the disturbing background noise, but the radio is sensitive
enough to open when any usable signal appears.
The correct SQ setting is very important for the SCAN function. The SQ threshold point decides
about SCAN Stopp or SCAN restart
Special frequently used channels
The CB community is using some channels for special purposes:
Channel 9 Emergency and Calling Channel, in Germany „Trucker Channel“
Channel 19 Trucker- Channel in some other countries
MEMORY- Operation
The MEMO key allows toggle switching between 5 preselected memory channels and the
standard channel selection.
• Press MEMO shortly and You will see the channel number and the memory location
number of the selected MEMO channel (1-5).
•
Use
UP/ DWN
to select between the memory locations 1 to 5.
• Short pressing MEMO will switch back to normal operation
