Albrecht AE75H User Manual (English)

Other manuals for Albrecht AE75H

Questions and Answers:

C
Courtney HopkinsJul 31, 2025
What to do if the Albrecht Receiver scan won’t stop?
- E
  Emily GriffithJul 31, 2025
  If the Albrecht Receiver scan won't stop, several factors could be at play. First, the squelch might need adjustment. Also, ensure that the antenna connection is secure. Another reason might be that one or more channels are locked out, so verify that the channels you want to scan are not locked out. It's also possible that the channel’s frequency isn’t stored in memory, so ensure the channel’s frequency is stored. Finally, the channel might not be active; in that case, wait for a transmission on the channel.
M
Michaela MartinezAug 9, 2025
Why does my Albrecht Receiver have improper reception?
- A
  Anthony FletcherAug 9, 2025
  If you're experiencing improper reception with your Albrecht Receiver, start by checking the antenna connection and try moving or repositioning the antenna. Additionally, try moving the receiver to a different location. If you are in a remote area, consider that you might need an optional multi-band antenna. Check with your dealer or local electronics store.
L
lmathisAug 19, 2025
What to do if Albrecht Receiver scan won’t start?
- D
  Dr. Stephanie Sparks PhDAug 19, 2025
  If the Albrecht Receiver scan won’t start, make sure you press the Scan button. If it still doesn't start, the squelch might need to be adjusted.

Albrecht AE75H Specifications

Frequency Coverage

frequency coverage 1	68-88 MHz
frequency coverage 2	108-137 MHz
frequency coverage 3	137-174 MHz
frequency coverage 4	380-512 MHz

Sensitivity and Selectivity

sensitivity 68-88 MHz	0.7 uV
sensitivity 108-137 MHz	1.0 uV
sensitivity 137-174 MHz	0.7 uV
sensitivity 380-512 MHz	0.7 uV
selectivity +/-10kHz	-6 dB
selectivity +/-18kHz	-50 dB

Spurious and IF Rejection

spurious rejection 68-88 MHz	50 dB at 78 MHz
spurious rejection 108-137 MHz	50 dB at 124 MHz
spurious rejection 137-174 MHz	50 dB at 154 MHz
if rejection 10.7 MHz	70 dB at 154 MHz

Scanning and Search Rates

scanning rate	Up to 25 channels/second
search rate	Up to 50 steps/second
delay time	2 seconds

Power and Audio

audio output power	200 mW Nominal (10% THD)
power requirements	9 V DC, 6 AA batteries
ac adapter/dc adapter	9V, 200 mA
current drain (squelched)	50 mA

Physical Characteristics

dimensions	171 (H) x 59 (W) x 40 (D) mm
weight	240 g without antenna and batteries
antenna impedance	50 ohms

View in Manual

Summary

Preparation and Powering

Power Sources

Details on scanner power options including internal batteries, AC, DC adapters, and rechargeable packs.

Battery Installation

Step-by-step guide for inserting AA batteries or a battery pack into the scanner.

Using Standard AC Power

Instructions and cautions for powering the scanner using an AC adapter.

Connecting the Scanner

Using Vehicle Battery Power

Guide on powering the scanner via a vehicle's cigarette-lighter socket with a DC adapter.

Charging Rechargeable Batteries

Information on the scanner's built-in charging circuit for rechargeable batteries.

Connecting the Antenna

Instructions on attaching the supplied flexible antenna and connecting optional antennas.

Using the Belt Clip

How to use the belt clip for convenient, hands-free carrying of the scanner.

Connecting Earphones or Extension Speaker

Guidance on connecting earphones for private listening and extension speakers for better audio.

Scanner Operation and Features

Scanner Keypad Overview

Explanation of the functions of various keys on the scanner's keypad.

Scanner Display Indicators

Description of symbols and indicators shown on the scanner's display screen.

Search Bands and Monitor Memory

Details on preprogrammed search bands and the use of monitor memory.

Turning On and Setting Volume/Squelch

Instructions for powering on the scanner and adjusting volume and squelch settings.

Storing Active Frequencies

Methods for manually storing frequencies into scanner channels.

Band Search and Direct Search

Procedures for searching for active frequencies within bands or from a specific frequency.

Moving Frequency from Monitor Memory

Steps to transfer a frequency from monitor memory to a specific channel.

Monitoring Stored Channels and Scanning

How to monitor a specific channel or initiate automatic channel scanning.

Clearing Channels

Procedure for deleting stored frequencies from scanner channels.

Special Features: Delay and Lockout

Explanation of the 2-second delay feature and how to lock out channels.

Display Backlight and Key Tone

How to use the display backlight and turn the key tone on or off.

Using the Keylock Feature

Instructions on how to enable and disable the keypad lock to prevent accidental changes.

General Scanning and Troubleshooting

Birdie Frequencies

Information about internal scanner signals (birdies) and how to identify them.

Specified Frequency Intervals

Details on the specific intervals at which frequencies are accessible in different bands.

Troubleshooting Common Issues

Guidance on diagnosing and resolving common problems with the scanner's operation.

Maintenance and Specifications

Resetting and Initializing the Scanner

Procedures for resetting or initializing the scanner to default settings.

Care and Maintenance

Recommendations for keeping the scanner in good working condition.

Scanner Specifications

Technical details and performance specifications of the AE75H scanner.
