Alcad CAD-704 - Advanced Input Settings; VHF-UHF Input (V;U 2) Configuration; UHF Input (U3 and U4) Configuration

- 19 -
MAIN MENU
To go back to the main menu, select INPUT V/U 1 and
press
↵
to confirm.
In any position of the menus INPUT U/V 1, INPUT U/V 2, INPUT U3 or INPUT
U 4 press the keys ▲▼ at the same time to go back to main menu.
INPUT VHF-UHF [2]
To set the INPUT V/U 2 parameters, press
↵
to enter the
menu.
Available channels:
BIII E5..E13 – DAB
UHF 21..48 with LTE700 5G filter
UHF 21..60 with LTE800 4G filter
UHF 21..69 without LTE filter
The input can be configured as BIII/DAB or UHF. Once a
filter is selected in BIII/DAB or UHF, the rest of the filters
must be from the same band.
The procedures described for input 1 apply to all settings.
INPUT UHF [3]
To set the INPUT U 3 parameters, press
↵
to enter the
menu.
Available channels:
UHF 21..48 with LTE700 5G filter
UHF 21..60 with LTE800 4G filter
UHF 21..69 without LTE filter
The procedures described for input 1 apply to all settings.
INPUT UHF [4]
To set the INPUT U 4 parameters, press
↵
to enter the
menu.
Available channels:
UHF 21..48 with LTE700 5G filter
UHF 21..60 with LTE800 4G filter
UHF 21..69 without LTE filter
The procedures described for input 1 apply to all settings.
>INPUT V/U 1
DC : OFF
INPUT V/U 2
INPUT U 3
INPUT U 4
