Table 7-22 Firewall rules for traffic coming into the 5620 SAM Auxiliary Cflowd
Server(s) from the Managed Network
Protocol From port On To port On Notes
UDP Any Managed Network 4739 Auxiliary Server(s) Cflowd flow records
from 7750 routers to
5620 SAM Cflowd
Auxiliary Server.
When there is a firewall at the interface that reaches the 5620 SAM Client(s) (NIC 3 on
Figure 8-2, “Distributed 5620 SAM Server/Database deployment with multiple network
interfaces” (p. 8-4)
), the following rules apply for FTP access to the 5620 SAM Auxiliary
by the OSS Client.
Table 7-23 Firewall rules for OSS Client communication to the 5620 SAM
Auxiliary Server(s)
Protocol From port On To port On Notes
TCP Any SAM-O Client 21/22 Auxiliary Server(s) (S)FTP requests
(logToFile statistics, and
call trace information)
TCP 21/22 SAM-O Client Any Auxiliary Server(s) (S)FTP responses
TCP > 1023 SAM-O Client Any Auxiliary Server(s) Passive (S)FTP ports for
data transfer (See
“FTP
between the 5620 SAM
Server and 5620 SAM
Auxiliary Statistics
Collector and the
managed network”
(p. 7-15)
)
Only for 5620 SAM Auxiliary Call Trace Collectors
TCP Any SAM-O Client 8086 Auxiliary Server(s) HTTP interface for
WebDAV for WTA
TCP Any SAM-O Client 8445 Auxiliary Server(s) HTTPS interface for
WebDAV for WTA
TCP Any SAM-O
3GPP-compliant Client
9735 Auxiliary Server(s) Corba interface to
access Call Trace
information
Table 7-24 FTP/SFTP Firewall rules for the 5620 SAM Cflowd Auxiliary Server(s)
Protocol From port On To port On Notes
TCP Any Auxiliary Server(s) 21/22 IPDR File Server (S)FTP requests
(logToFile statistics, and
call trace information)
TCP 21/22 Target File Server Any Auxiliary Server(s) (S)FTP responses
Security Firewall and NAT rules
....................................................................................................................................................................................................................................
....................................................................................................................................................................................................................................
5620 SAM
3HE-09809-AAAG-TQZZA 13.0 R7
Issue 1 December 2015
7-25
