Table 7-24 FTP/SFTP Firewall rules for the 5620 SAM Cflowd Auxiliary
Server(s) (continued)
Protocol From port On To port On Notes
TCP > 1023 Target File Server Any Auxiliary Server(s) Passive (S)FTP ports for
data transfer (See
“FTP
between the 5620 SAM
Server and 5620 SAM
Auxiliary Statistics
Collector and the
managed network”
(p. 7-15)
)
When there is a firewall at the interface that communicates with the 5620 SAM Servers,
the following rules apply for inter process communication. If multiple interfaces are used
for 5620 SAM Server communication to the clients (GUI and OSS) and auxiliary servers,
the network traffic from the 5620 SAM Auxiliaries could pass through the SAM client
interface (NIC 3 on
Figure 8-2, “Distributed 5620 SAM Server/Database deployment
with multiple network interfaces” (p. 8-4)
) or the SAM network interface (NIC 1 on
Figure 8-2, “Distributed 5620 SAM Server/Database deployment with multiple network
interfaces” (p. 8-4)
) of the 5620 SAM Auxiliary.
Table 7-25 Firewall rules for inter process communication on the 5620 SAM
Auxiliary Statistics / Call Trace Server(s)
Protocol From port On To port On
TCP Any Auxiliary Server(s) 1095 Auxiliary Server(s)
TCP Any Auxiliary Server(s) 12300-12307 Auxiliary Server(s)
TCP 12300-12307 Auxiliary Server(s) Any Auxiliary Server(s)
TCP Any Auxiliary Server(s) 12800 Auxiliary Server(s)
TCP 12800 Auxiliary Server(s) Any Auxiliary Server(s)
Table 7-26 Firewall rules for inter process communication on the 5620 SAM
Cflowd Auxiliary Server(s)
Protocol From port On To port On
TCP Any Auxiliary Server(s) 1090 Auxiliary Server(s)
TCP Any Auxiliary Server(s) 1098 Auxiliary Server(s)
TCP Any Auxiliary Server(s) 1099 Auxiliary Server(s)
TCP Any Auxiliary Server(s) 4444 Auxiliary Server(s)
TCP Any Auxiliary Server(s) 4445 Auxiliary Server(s)
TCP Any Auxiliary Server(s) 4446 Auxiliary Server(s)
TCP Any Auxiliary Server(s) 4447 Auxiliary Server(s)
