Table 7-26 Firewall rules for inter process communication on the 5620 SAM
Cflowd Auxiliary Server(s) (continued)
Protocol From port On To port On
TCP Any Auxiliary Server(s) 4457 Auxiliary Server(s)
TCP Any Auxiliary Server(s) 8083 Auxiliary Server(s)
TCP Any Auxiliary Server(s) 9443 Auxiliary Server(s)
TCP Any Auxiliary Server(s) 9990 Auxiliary Server(s)
TCP Any Auxiliary Server(s) 9999 Auxiliary Server(s)
When there is a firewall at the interface that communicates with the 5620 SAM Servers,
the following rules apply. If multiple interfaces are used for 5620 SAM Server
communication to the clients (GUI and OSS) and auxiliary servers, the network traffic
from the 5620 SAM Auxiliaries could pass through the SAM client interface (NIC 3 on
Figure 8-2, “Distributed 5620 SAM Server/Database deployment with multiple network
interfaces” (p. 8-4)
) or the SAM network interface (NIC 1 on Figure 8-2, “Distributed
5620 SAM Server/Database deployment with multiple network interfaces” (p. 8-4)
)of
the 5620 SAM Auxiliary.
Table 7-27 Firewall rules for traffic coming into the 5620 SAM Auxiliary Statistics
/ Call Trace Server(s) from the 5620 SAM Server(s)
Protocol From port On To port On
TCP 1097 Server(s) Any Auxiliary Server(s)
TCP 1099 Server(s) Any Auxiliary Server(s)
TCP 4447 Server(s) Any Auxiliary Server(s)
TCP > 32768 Server(s) > 32768 Auxiliary Server(s)
When there is a firewall at the interface that reaches the 5620 SAM Client(s) (NIC 3 on
Figure 8-2, “Distributed 5620 SAM Server/Database deployment with multiple network
interfaces” (p. 8-4)
) and NAT is used on the 5620 SAM Auxiliary Server(s), the
following rules apply to allow the OSS clients to collect the logToFile accounting
statistics files. Services require the use of public addresses.
Table 7-28 Additional Firewall rules required to allow services on the 5620 SAM
client(s) to communicate with the 5620 SAM Auxiliary(s) if NAT is
used on the Auxiliary Server(s).
Protocol From port On To port On
TCP Any Auxiliary Server Public
Address
21 Auxiliary Server Private
Address
Security Firewall and NAT rules
....................................................................................................................................................................................................................................
....................................................................................................................................................................................................................................
5620 SAM
3HE-09809-AAAG-TQZZA 13.0 R7
Issue 1 December 2015
7-27
