Table 7-28 Additional Firewall rules required to allow services on the 5620 SAM
client(s) to communicate with the 5620 SAM Auxiliary(s) if NAT is
used on the Auxiliary Server(s). (continued)
Protocol From port On To port On
TCP 21 Auxiliary Server Public
Address
Any Auxiliary Server Private
Address
TCP > 1023 Auxiliary Server Public
Address
> 1023 Auxiliary Server Private
Address
When there is a firewall at the interface that reaches the SAM management network (NIC
1on
Figure 8-2, “Distributed 5620 SAM Server/Database deployment with multiple
network interfaces” (p. 8-4)
), the following rules apply.
Table 7-29 Firewall rules for traffic coming into the 5620 SAM Auxiliary
Server(s) from the 5620 SAM Database Server(s)
Protocol From port On To port On
TCP 1523 Database Server(s) Any Auxiliary Server(s)
TCP 9002 Database Server(s) Any Auxiliary Server(s)
When there is a firewall at the interface that reaches the SAM management network (NIC
1on
Figure 8-2, “Distributed 5620 SAM Server/Database deployment with multiple
network interfaces” (p. 8-4)
), the following rules apply.
Table 7-30 Firewall rules for traffic coming into the 5620 SAM Auxiliary
Server(s) from the 5620 SAM Server(s)
Protocol From port On To port On
TCP Any Server(s) 12300-12307 Auxiliary Server(s)
TCP 12300-12307 Server(s) Any Auxiliary Server(s)
TCP Any Server(s) 12800 Auxiliary Server(s)
TCP 12800 Server(s) Any Auxiliary Server(s)
Table 7-31 Firewall rules for traffic between redundant 5620 SAM Auxiliary
Statistics Collector Servers.
Protocol From port On To port On
TCP Any Auxiliary Statistics
Collector
22 Auxiliary Statistics
Collector
TCP Any Auxiliary Statistics
Collector
9010 Auxiliary Statistics
Collector
Security Firewall and NAT rules
....................................................................................................................................................................................................................................
....................................................................................................................................................................................................................................
7-28
5620 SAM
3HE-09809-AAAG-TQZZA 13.0 R7
Issue 1 December 2015
