Table 7-35 Firewall rules for traffic between the 5620 SAM Client and the
eNodeB NEM (continued)
Protocol From port On To port On Notes
TCP Any 5620 SAM Client(s) 830 Managed Network NetConf over SSH
Table 7-36 Firewall rules for traffic between the 5620 SAM Client and GNEs
Protocol From port On To port On Notes
TCP Any 5620 SAM Client(s) 80 Managed Network HTTP (See GNE vendor
for specifics)
TCP Any 5620 SAM Client(s) 443 Managed Network HTTPS (See GNE
vendor for specifics)
Table 7-37 Firewall rules for traffic between the 5620 SAM Client (NEtO) and
9500MPR (MSS-8/4/1)
Protocol From port On To port On Notes
TCP 20 5620 SAM Client(s) Any Managed Network Active FTP
TCP Any 5620 SAM Client(s) 21 Managed Network FTP
TCP 21 5620 SAM Client Any Managed Network FTP
TCP 22 5620 SAM Client Any Managed Network sFTP
TCP Any 5620 SAM Client 22 Managed Network sFTP
TCP Any 5620 SAM Client(s) 23 Managed Network Telnet
TCP Any 5620 SAM Client(s) 80 Managed Network HTTP
UDP Any 5620 SAM Client(s) 161 Managed Network SNMP
TCP >1023 5620 SAM Client(s) >1023 Managed Network Passive FTP
UDP 5010 5620 SAM Client(s) 5010 Managed Network SNMP
Table 7-38 Firewall rules for traffic between the 5620 SAM Client (NEtO) and
9500MPR (MSS-1C / MPR-e)
Protocol From port On To port On Notes
TCP 20 5620 SAM Client(s) Any Managed Network Active FTP
TCP 21 5620 SAM Client Any Managed Network FTP
TCP Any 5620 SAM Client(s) 23 Managed Network Telnet
UDP Any 5620 SAM Client(s) 161 Managed Network SNMP
TCP >1023 5620 SAM Client(s) >1023 Managed Network Passive FTP
UDP 5010 5620 SAM Client Any Managed Network SNMP
