Table 7-38 Firewall rules for traffic between the 5620 SAM Client (NEtO) and
9500MPR (MSS-1C / MPR-e) (continued)
Protocol From port On To port On Notes
UDP Any 5620 SAM Client 11500 Managed Network Equipment View (GUI)
Table 7-39 Firewall rules for traffic between the 5620 SAM Client (NEtO) and
9400AWY
Protocol From port On To port On Notes
TCP Any 5620 SAM Client(s) 21 Managed Network FTP
TCP 21 5620 SAM Client Any Managed Network FTP
TCP Any 5620 SAM Client(s) 23 Managed Network Telnet
TCP Any 5620 SAM Client(s) 80 Managed Network HTTP
UDP Any 5620 SAM Client(s) 161 Managed Network SNMP
TCP >1023 5620 SAM Client(s) >1023 Managed Network Passive FTP
UDP 5010 5620 SAM Client Any Managed Network SNMP
Table 7-40 Firewall rules for traffic between the 5620 SAM Client and Omni
Switches
Protocol From port On To port On Notes
TCP Any 5620 SAM Client(s) 80 Managed Network HTTP
TCP Any 5620 SAM Client(s) 443 Managed Network HTTPS
