UDS-101

MSS-8 Microwave Service Switch Shelf

3-6

3EM23952AA

Issue 01, September 2009

MSS-8 shelf slot 1 is dedicated to the main CSM module and is required in

every application. See figure 101-3 to see an example of the MSS-8 shelf

configured in the unprotected CSM configuration. Slot 2 is dedicated for an

optional spare CSM module for protected CSM configurations. See figure 101-4

to see an example of the MSS-8 shelf configured in the protected CSM

configuration.

Figure 101-3. MSS-8 Shelf, Unprotected CSM Configuration

950-0006-1

072209

Filler Panel

Any Transponder

CSM

(Main)

Fan
