3EM23952AA

Issue 01, September 2009

UDS-101

MSS-8 Microwave Service Switch Shelf

3-7

MSS-8 shelves supports up to six P32E1DS1 module in unprotected DS1

aggregation configurations. Supports up to three pairs of P32E1DS1 modules

in 1+1 EPS protected DS1 aggregation configurations. In 1+1 EPS protected

configuration, the main P32E1DS1 modules are equipped in slots 3, 5, and/or

7, and the spare (protection) P32E1DS1 modules are equipped in slots 4, 6,

and/or 8 respectively.

See figure 101-5 to see an example of a stand-alone MSS-8 shelf configured

with two pairs of P32E1DS1s in slots 3 through 6 in the protected 1+1 EPS

configuration and slots 7 and 8 configured in the unprotected configuration.

Figure 101-4. MSS-8 Shelf, Protected CSM Configuration

950-0005-1

072209

CSM

(Protect)

Any Transponder

CSM

(Main)

Fan
