The Alcatel-Lucent 3 port PoE Gigabit Adapter has single color LEDs to indicate the correct
functionality of all the components and functions. The LEDs can be:
- OFF (if the monitored function or component is not active or connected),
- ON (if the monitored function is active or connected),
- BLINKING (if the monitored component is transmitting and receiving).
table 2.1: LED indicators for Alcatel-Lucent PoE GA
LED name Function Condition Meaning
POWER System power
indicator
ON the system power is
connected
LAN LINK/ACT LAN port indicator ON the LAN port link is
established
BLINKING the LAN port is
transmitting and
receiving
LAN 1000M LAN port gigabit
speed indicator
ON the LAN port is linked
at 1000 Mbps
IP PHONE LINK/ACT IP Phone port
indicator
ON the IP phone port link
is established
BLINKING the IP phone port is
transmitting and
receiving
IP PHONE POE ON IP Phone port power
output indicator
ON the phone port PoE
function is active
IP PHONE POE
ERROR
IP Phone port power
fault indicator
ON the phone consumed
more than 6.49W
the phone port PoE
function is switched off
IP PHONE VLAN
ENABLE
IP Phone port VLAN
enable indicator
ON the VLAN function of
the phone port is
active
PC LINK/ACT PC port indicator ON the PC port link is
established
BLINKING the PC port is
transmitting and
receiving
2
2-1
