Backup Power Supply Components OmniSwitch 6800 Series Chassis and Hardware Components
page 2-50 OmniSwitch 6800 Series Hardware Users Guide June 2007
3 Once the captive screws are completely disengaged, grasp both captive screws and slowly pull the
power supply out of the power supply bay.
Removing the Backup Power Supply
4 Store the power supply in a secure, static-free location.
5 Refer to the important blank cover panel requirement on page 2-51.
