ELECTRICAL CHARACTERISTICS
21
6.7. ESD Test Results
Test Description: ESD Testing was performed on a Zapmaster system using the Human-
Body-Model (HBM) and Machine-Model (MM), according to MIL-STD 883 and EIAJ IC-
121 respectively.
• Human-Body-Model stresses devices by sudden application of a high voltage supplied by
a 100pF capacitor through 1.5k-ohm resistance.
• Machine-Model stresses devices by sudden application of a high voltage supplied by a
200pF capacitor through very low (0 ohm) resistance.
Test Circuit & Condition
- Zap Interval: 1 second
- Number of Zaps: 3 positive and 3 negative at room temperature
- Criteria: I-V Curve Tracing
ESD Data
Model Mode S/S Target Results
HBM Vdd, Vss, I/C 15 6000V PASS
MM Vdd, Vss, I/C 15 200V PASS
